Purpose of hole disc planter

It is suitable for planting flowers, vegetables, tobacco, fruits, medicinal materials, herbage and so on.

Product Feature

Main body with aluminum body and accessories, stainless steel screws.
PLC programmable control, accurate and reliable.
Automatic photoelectric induction seeding.
German vacuum pneumatic system, pressure suction adjustable.
Equipped with independent fault warning system and LED light emitting tube fault display.
for different number of slots.
With printer or RS485 interface, it can connect printer and computer, and can record the change of temperature parameters (optional).

Technical indicators

Sowing point plate 32-288 points
Use air pressure of 0.8 MP
0.2-20mm seeds can be sown
Conventional international standardized round seed seeding accuracy above 98%.
Power supply voltage 220V 50Hz
Working environment temperature -20~40℃
Input power 300W
External dimensions W×D×H(mm) 1200×600×1350
